Features:
Pure sine wave inverter
Programmable supply priority for PV, battery or grid.
High PV input voltage range (55~450VDC)
Built-in Max 110A MPPT solar charge
Compatible with lithium-ion battery
Supports BMS communication with lithium battery
Smart battery charging design to optimize battery life
Overload, high temperature and short circuit protection for inverter output
Cold start function
Intelligent fan speed adjustment
WIFI&GPRS available for lOS and android (optional)
|
MODEL |
ANJ-SP-4200H-24V |
|
Rated Power |
4200VA/3800W |
|
INPUT |
|
|
Current Voltage |
230 VAC |
|
Selectable Voltage Range |
170-280 VAC (for PCs) 90-280 VAC (for Household appliances) |
|
Frequency Range |
50 Hz/60 Hz (Automatic detection) |
|
OUTPUT |
|
|
AC Voltage Control (Batt.Mode) |
230 VAC±5 % |
|
Overvoltage Protection |
8000 VA |
|
Efficiency (Peak) |
98% |
|
Transfer Time |
10 ms (für PCs) 20 ms (für Haushaltsgeräte) |
|
Waveform |
Pure Sine Wave |
|
BATTERY |
|
|
Battery Voltage |
24VDC |
|
Floating Charging Voltage |
27VDC |
|
Overload Protection |
31VDC |
|
SOLAR CHARGER |
|
|
Maximum PVArray Performance |
5000W |
|
MaximumPVArrayOpenCircuitVoltage |
450VDC |
|
MPPTRange@Operating Voltage |
55-450 VDC |
|
Maximum Solar Charging Current |
110A |
|
MaximumACCharging Current |
80A |
|
Maximum Efficiency |
98% |
|
BODILY |
|
|
Dimension.D*W*H(mm) |
423*290*100mm |
|
Net Weight (kg) |
7 kg |
|
OPERATING ENVIRONMENT |
|
|
Humidity |
5% to 95% Relative Humidity (Non-Condensing) |
|
Operating Temperature |
-10°C to 55°C |
|
Storage Temperature |
-15 °C bis 60 °C |
